Further Details of the New Bean 25-cwt. Chassis
Page 48
If you've noticed an error in this article please click here to report it so we can fix it.
wE have already made several references in our columns to the new 25-cwt. chassis which is about to be marketed by Bean Cars, Ltd., of Tipton. As previously intimated, the chassis closely follows the design of the company's 20-cwt. model, although several differences are apparent. The new chassis has a four-cylindered engine with a bore of 75 mm. and a stroke of 130 mm., itt which the lubrication is effected by a gear-type Pump submerged in the sump, and cooling is on the thertno-siphonic principle.
The drive is conveyed through a clutch of the single, dry-plate type to a four-speed-and-reverse gearbox in
c26
which the changes of gear are effected by a lever on the right-hand side. The gear ratios are as follow :—Top speed (direct), 6.12 to 1; third speed, 10.12 to 1; second speed, 13.95 to 1; first speed, 25.26 to 1; reverse, 33.68 to 1. The propeller shaft is of the open type and has fabric disc couplings at each end, -and it connects with the fully floating spiral-bevel-driven rear axle.
Internal-expanding brake shoes in 15-in.-diameter steel drums on the rear hubs are provided, the foot-brake and the hand-brake lever operating separate shoes, _
r.Phe Wheelbase of the new 25-cwt. model is 11 'ft. I. in. and its track
4 ft. S ins., the clearance under, the front axle being 11 ins. and under the rear axle 0 ins. It weighs 28 cwt,, and,. sells in chassis form (with selfstarter and spare wheel) at ±285.
The standard boxyan body, which is being provided for the chassis, is 8 ft. 2 ins. long, 4 ft. 8 ins, wide, and 5 ft. high. Its large doors at the rear are hinged so as to permit a full-width opening. The van sells for £340.
The vehicle can also be supplied as a drop-sided lorry or as a flat-platform lorry. In this case the length of the body is 7 ft. 11 ins., and its width 5 ft. 4 ins., whilst the height of the sides of the drop-sided lorry is 1 ft. 6i
