PLANS are being made to produce British-built Reo goods and passenger chassis employing power and transmission units imported from America. These models, for export only, have been developed in conjunction with Seddon Motors, Ltd., and will be built in that company's Woodstock Factory, Oldham. Permission has been given by the Board of Trade to import engines, clutches and gearboxes for six prototypes, pending the granting of a licence.

The Reo Gold Crown 331-cubic-in. (5.43-litre) six-cylindered 140 b.h.p. petrol engine is to be installed, together with a Borg and Beck clutch and Clarke five-speed gearbox having a direct or overdrive-top ratio. The net power of this overhead-valve unit, complete with all accessories, is 128 b.h.p. at 3,200 r.p.m., and 260 lb.-ft. torque is available at 1,200 r.p.m.

Wet Sleeves

Replaceable wet sleeves are fitted to the cylinder block with synthetic seals to prevent leakage of water. Steelbacked copper-lead-lined shells are used for the main and connecting-rod bearings. Although the inlet and exhaust valves are made from a standard silichrome steel, the exhaust valves incorporate sodium cooling.

Mounted as a unit with the engine. the five-speed overdrive-top gearbox has helical gears for the third and fifth ratios. Overdrive is 0.799 to 1 and the fourth gear is direct drive. The alternative direct-drive-top gearbox has

A38 ratios of 7.58, 4.38, 2.4, 1.478 and 1 to 1 forward.

The remainder of

the transmission units, frame and components of the I6-ft. 4-in.-wheelbase passenger chassis and 6-ton goods model are of British manufacture. Propeller shafts with Hardy Spicer couplings are employed and the rear axle has a hypoid drive.

A prototype passenger chassis now being shown Brussels retains the typically American transmission brake, which, operated by the lever, takes effect on a drum attached to the gearbox output shaft. This is to be an optional fitting according to the customer's requirements.

The main braking system incorporates a Clayton Dewandre vacuum servo and Lockheed hydraulic master cylinder operating Girling two-leading-shoe units at all wheels. The alternative parking brake arrangement is linked mechanically to the rear wheels only.

A straight parallel frame is employed for the goods model, whereas the passenger version is of maximum width from the gearbox to the rear crossmember and tapers at the front. There is an upsweep over the rear axle of the passenger model.

Dual-marked tyre equipment of 9.00 by 20/36 by 8-in, is fitted to the passen

at

ger chassis, which weighs 3 tons 2 cwt. unladen and is designed for a maximum gross weight of 8 tons.

The vehicle shown by Ets. Jean Hocke, Rue Gaucheret.30, Brussels, the distributor of Seddon and Reo vehicles in Belgium, is equipped with left-hand control, the steering geaf being of Marks pattern.

The 6-tonner, also a forward-control model, will have the Clarke five-speed gearbox installed and a spiral-bevel final-drive unit. This is to be a straightframe left-hand-control chassis weighing under 3 tons unladen. The braking system will be the same as for the passenger chassis, and the transmission brake optional.

Three prototypes now being prepared at Oldham will be operated in Canada and America.

The address of Reo Motors, Ltd., is 97, High Street, Staines, Middlesex.
